LA10+LA18B LINE ARRAY SPEAKER

Name: LA10+LA18B LINE ARRAY SPEAKER
Brand: Guangzhou Huiyin Audio Co., Ltd.
SKU: LA10+LA18B
Price: 5300 USD
Availability: InStock

LA10+LA18B With multi-functional functions and advanced audio technology, the LA series of multi-functional line array speakers provide excellent audio performance in various applications and accurately meet different sound reinforcement needs. This speaker is used in performances, stadiums, theaters, banquet halls, multi-function halls and various high-end occasions

0.0 (0 Reviews)

0 Sold

$5,300.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

Description
Company profile

Specification

	LA10	LA18B	R1300
System type	1 x 10-inch two-way two-driver curve array speaker	Single 18-inch subwoofer passive speaker
Frequency response	70Hz -18 kHz（±3）	40Hz-250Hz(±3dB) 35Hz-300Hz(-10 dB)	20Hz~20kHz，+1/-1dB
Sensitivity	:HF:103dB LF:100dB	100dB	0.775V
Nominal impedance	:HF:16Ω LF:16Ω	8Ω
rated power	:HF:80W LF:300W	800W	Stereo 8Ω): 2×1300W Stereo 4Ω): 2×1800W
Bass unit	1×10 inch neodymium magnet carbon fiber woofer (75mm voice coil	18-inch (100mm voice coil) neodymium magnet ultra-low driver
Tweeter	1×3 inch neodymium tweeter (75mm voice coil)
Nominal coverage angle	（H x V）:100°×10°
Maximum sound pressure level (SPL)	:HF:122/128 dB LF:124/130 dB	128dB/134dB
hanging accessories	Four-point hanging adjustable from 0°-10°
Connect socket	Professional NL4MP four-core socket 2 2+2-HF, 1+1-LF
Dimensions (W×D×H)	500x325x274（mm）	500×673×584（mm	88×483×390mm
Product net weight (kg)	17kg	45kg	23.8kg
Bridged mono mode 8Ω			3500W
Total harmonic distortion (THD)			≤0.5%
Damping coefficient:			≥200:1
Voltage amplification			(0.775V)
Signal-to-noise ratio (A-weighted)			≥97dB
Input impedance (rated)			20KΩ(balanced)/10KΩ(unbalanced)
Separation:			≥60dB
input connector			One balanced XLR per channel
Output connector (speaker connection interface)			4-POLE Speakon per channel
Compression ratio			20:1
power supply			AC 220V 50Hz~60Hz

Features

Selected high-quality and high-efficiency accessories
It is composed of a high-performance high-pressure neodymium tweeter and a low-distortion carbon fiber neodymium woofer.
High frequency, delicate and transparent
Thick and powerful low frequency
The speaker adopts high temperature resistant pure copper voice coil
The cabinet adopts precise CNC machining combined with complex slotting and wedging technology.
Change the hanging or stacking method to meet different occasions, convenient and safe
Application
Main PA for medium-sized PA systems
Mobile performances
gymnasium
Theater/theater/auditorium
